Specifications
-
Camera
-
- Image Sensor
-
- 1/2.8" 4K Exmor CMOS
-
- Effective Picture Elements
-
- 8 Megapixels
-
- Output Resolutions
-
- 4K/30, 4K/29.97, 4K/25, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/50, 720p/60, 720p/59.94, 720p/50
-
- Minimum Illumination
-
- 0.4 lux (IRE50, F1.6, 30fps)
-
- S/N Ratio
-
- ≥ 50dB
-
- Gain
-
- Auto, Manual
-
- TV Line
-
- 1400 (Center)
-
- Shutter Speed
-
- 1/1 to 1/32,000 sec
-
- Exposure Control
-
- Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
-
- White Balance
-
- Auto, Manual
-
- Optical Zoom
-
- 12X
-
- Digital Zoom
-
- 12X
-
- Sensor Zoom
-
- 2X
-
- Viewing Angles
-
- DFOV : 78° (Wide) to 7° (Tele)
- HFOV : 70° (Wide) to 6° (Tele)
- VFOV : 42° (Wide) to 3° (Tele)
-
- Focal length
-
- f = 3.9 mm (Wide) to 46.8 mm (Tele)
-
- Aperture (Iris)
-
- F = 1.6 (Wide) to 2.8 (Tele)
-
- Minimum Working Distance
-
- 0.3 m (Wide), 1.5m (Tele)
-
- Pan / Tilt Angles
-
- Pan : ±170°, Tilt : +90° / -30°
-
- Pan / Tilt Speed (Manual)
-
- Pan : 0.1° to 100° / sec, Tilt : 0.1° to 100° / sec
-
- Preset Speed
-
- Pan : 200° / sec, Tilt : 200° / sec
-
- Preset Positions
-
- 10 (IR), 256 (RS-232 / RS-422 / IP)
-
- Camera Control - Interfaces
-
- RS-232 (DIN8), RS-422 (RJ45), IP
-
- Camera Control - Protocols
-
- VISCA (RS-232 / RS-422 / IP), PELCO-D & PELCO-P (RS-232 / RS-422), CGI (IP)
-
- Image Processing
-
- Noise Reduction (2D / 3D), Flip, Mirror
-
- Power Frequencies
-
- 50 Hz, 60 Hz
-
AI Auto Tracking Functions
-
- Tracking Modes
-
- Presenter Mode, Zone Mode
-
Audio
-
- Channels
-
- 2ch Stereo
-
- Codecs
-
- AAC-LC (48 / 44.1 / 32 / 24K), G.711, PCM (8K)
-
- Sample Rates
-
- 48 / 44.1 / 32 / 24 / 16 / 8 KHz
-
Interface
-
- Video Outputs
-
- HDMI, IP, USB
-
- Audio Outputs
-
- HDMI, IP, USB
-
- Audio Inputs
-
- MIC in, Line in
-
General
-
- Power Requirement
-
- AC 100 - 240V to DC 12V/5A
-
- Power Consumption
-
- 18W
-
- PoE
-
- PoE+
-
- Dimensions (W x H x D)
-
- 180.0 x 183.5 x 145.0 mm
-
- Net Weight
-
- 1.7 (±0.1) kg
-
- Application
-
- Indoor
-
- Tally Lamp
-
- Yes
-
- Security
-
- Kensington slot
-
- Remote Control
-
- Infrared
-
- Operating Conditions
-
- Temperature: 0°C to +40°C Humidity: 20% to 80%
-
- Storage Conditions
-
- Temperature: -20°C to +60°C Humidity: 20% to 95%
-
IP Streaming
-
- Resolution
-
- 4K 30fps
-
- Network Video Compress Formats
-
- H.264, H.265, MJPEG
-
- Maximum Frame Rate
-
- 4K 30fps
-
- Bit-Rate Control Modes
-
- VBR, CBR (selectable)
-
- Range of Bit-Rate setting
-
- 512 Kbps to 32 Mbps
-
- Network Interfaces
-
- 10 / 100 / 1000 Base-T
-
- Multi-stream Capability
-
- 2 (RTSP / Web Page), 1080p 60fps (max.)
-
- Network Protocols
-
- IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP
-
- NDI®|HX Capability
-
- Yes (NDI HX2)
-
USB
-
- Connector
-
- USB 3.0
-
- Video Formats
-
- MJPEG, YUY2
-
- Maximum Video Resolution
-
- 2160p
-
- USB Video Class (UVC)
-
- UVC 1.1
-
- USB Audio Class (UAC)
-
- UAC 1.0
-
Web UI
-
- Live Video Preview
-
- Yes
-
- Camera PTZ Control
-
- Pan, Tilt, Zoom, Focus, Preset Control
-
- Camera/Image Adjustment
-
- Exposure, White Balance, Picture
-
- Network Configuration
-
- DHCP, IP Address, Gateway, Subnet Mask, DNS
-
Software Tools
-
- IP Search and Configuration Tool
-
- Support Windows® 7 or later
-
- PTZ Management
-
- Support Windows® 7 or later
-
- PTZ Control Panel
-
- Support iPadOS® v11 or later
-
- CaptureShare
-
- Support Windows® 7 or later
-
Warranty
-
- Camera
-
- 3 Years
-
- Accessories
-
- 1 Year
-
- Package Contents
-
- Camera, Remote Control, Power Adapter, Power Cord, Cable Ties (x 5), Screws (x 10), Cable Fixing Plates (x 2), Ceiling Mount Brackets (x 2), Quick Start Guide
-
- Optional Accessories
-
- AVer CL01 PTZ Camera Controller, L-Type Wall Mount, RS-232 In/Out Cable, Din 8 To D-Sub 9 Cable
* Specifications may vary depending on location and are subject to change without notice.
