จำหน่าย Aver PTC310UN
AI Auto Tracking NDI®|HX PTZ Camera
The PTC310UN AI Auto Tracking PTZ Camera makes powerful and reliable Pro AV capability available to everyone.
Aver PTC310UN

The PTC310UN AI Auto Tracking PTZ Camera makes powerful and reliable Pro AV capability available to everyone. Drawing inspiration from the AVer Professional PTZ Camera family, the PTC310UN features in-house AI functions like Presenter Mode and Zone Mode auto tracking, thanks to Human Detection processing. Combine the 12X Optical Zoom lens and 4K resolution with hybrid auto tracking and smooth PTZ functions for broadcasting, streaming, or recording. Your exciting journey of audio and video capturing starts here!

  • 4K Ultra HD Resolution
  • 12X Optical Zoom
  • IP/HDMI/USB/3G-SDI
  • Human Detection AI
  • Presenter Mode
  • Zone Mode
  • Hybrid Mode
  • Exclusive Ceiling Mount

Full NDI®|HX for Greater Reach

The PTC310UN complies with the most rigorous NDI standards to deliver the lowest latency for on-air camera control, switching, and streaming - all via IP connection. It makes live broadcasts faster and simpler, allowing users to stream for larger audiences without complicated and expensive equipment. Design efficient and flexible IP workflows at will.

4K Output Resolution

Equipped with 4K resolution, the PTC310UN provides ultra-precise auto tracking. The PTC310UN also features a Sony sensor that maintains a truly impressive video performance through every frame of your production.

12X Optical Zoom & 2X Sensor Zoom

The zoom power of PTC310UN camera reaches an incredible 24X (12X optical and 2X sensor zoom). It works even while the camera is panning and tilting, allowing you to highlight content and rapidly change shooting angles. Operate a closer and clearer video feed with the unbeatable PTZ performance of the PTC310UN.

Human Detection AI

Welcome AVer’s most advanced AI tool yet—Human Detection. This highly accurate processing function enables PTC310UN to easily detect and capture human forms and moving objects in seconds. Never miss a tracking target again.

Click & Track

Redirect focus in an instant with the PTC310UN. Simply click on a target to quickly adjust the shooting angle and initiate precise tracking. This advanced feature is easy for anyone to operate via remote control or Web UI.

Presenter Mode

Track your target everywhere with Presenter Mode. This feature gives presenters the flexibility to leave the stage and interact with the audience, all while being continuously tracked. The camera stays locked on its target, even if other people or objects get in the way.

Zone Mode

Zone Mode enhances your ability to capture content on multiple displays. Create up to four Content Zones to steadily capture the content on display rather than the presenter’s movements.

Hybrid Mode

Hybrid Mode provides the utmost freedom of movement for performing artists. Preset effective areas for Zone Tracking in advance,
and once you step into those areas, you will be targeted together with the content. When you are outside, you are just like in Presenter Mode.

Specifications

  • Camera

  • Image Sensor
    • 1/2.8" 4K Exmor CMOS
  • Effective Picture Elements
    • 8 Megapixels
  • Output Resolutions
    • 4K/30, 4K/29.97, 4K/25, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/50, 720p/60, 720p/59.94, 720p/50
  • Minimum Illumination
    • 0.4 lux (IRE50, F1.6, 30fps)
  • S/N Ratio
    • ≥ 50dB
  • Gain
    • Auto, Manual
  • TV Line
    • 1400 (Center)
  • Shutter Speed
    • 1/1 to 1/32,000 sec
  • Exposure Control
    • Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
  • White Balance
    • Auto, Manual
  • Optical Zoom
    • 12X
  • Digital Zoom
    • 12X
  • Sensor Zoom
    • 2X
  • Viewing Angles
    • DFOV : 78° (Wide) to 7° (Tele)
    • HFOV : 70° (Wide) to 6° (Tele)
    • VFOV : 42° (Wide) to 3° (Tele)
  • Focal length
    • f = 3.9 mm (Wide) to 46.8 mm (Tele)
  • Aperture (Iris)
    • F = 1.6 (Wide) to 2.8 (Tele)
  • Minimum Working Distance
    • 0.3 m (Wide), 1.5m (Tele)
  • Pan/Tilt Angles
    • Pan : ±170°, Tilt : +90° / -30°
  • Pan/Tilt Speed (Manual)
    • Pan : 0.1° to 100° /sec, Tilt : 0.1° to 100° /sec
  • Preset Speed
    • Pan : 200° /sec, Tilt : 200° /sec
  • Preset Positions
    • 10 (IR), 256 (RS-232)
  • Camera Control - Interfaces
    • RS-232 (DIN8), RS-422 (RJ45), IP
  • Camera Control - Protocols
    • VISCA (RS-232 / RS-422 / IP), PELCO-D & PELCO-P (RS-232 / RS-422), CGI (IP)
  • Image Processing
    • Noise Reduction (2D / 3D), Flip, Mirror
  • Power Frequencies
    • 50Hz, 60Hz
  •
  • AI Auto Tracking Functions

  • Tracking Modes
    • Presenter Mode, Zone Mode
  •
  • Audio

  • Channels
    • 2ch (Stereo)
  • Codecs
    • AAC-LC (48 / 44.1 / 32 / 24K), G.711, PCM (8K)
  • Sample Rates
    • 48 / 44.1 / 32 / 24 / 16 / 8 KHz
  •
  • Interface

  • Video Outputs
    • 3G-SDI, HDMI, IP, USB
  • Audio Outputs
    • 3G-SDI, HDMI, IP, USB
  • Audio Inputs
    • MIC / Line in
  •
  • General

  • Power Requirement
    • AC100V-AC240V to DC12V/5A
  • Power Consumption
    • 18W
  • PoE
    • PoE+
  • Dimensions (W x H x D)
    • 180.0 x 183.5 x 145.0 mm
  • Net Weight
    • 1.7 (±0.1) kg
  • Application
    • Indoor
  • Tally Lamp
    • Yes
  • Security
    • Kensington slot
  • Remote Control
    • Infrared
  • Operating Conditions
    • Temperature: 0°C to +40°C ; Humidity: 20% to 80%
  • Storage Conditions
    • Temperature: -20°C to +60°C ; Humidity: 20% to 95%
  •
  • IP Streaming

  • Resolution
    • 4K 30fps
  • Network Video Compress Format
    • H.264, H.265, MJPEG
  • Maximum Frame Rate
    • 4K 30fps or 1080p 60fps
  • Bit-rate Control Modes
    • VBR, CBR (selectable)
  • Range of Bit-Rate Setting
    • 512 Kbps to 32 Mbps
  • Network Interface
    • 10/100/1000 Base-T
  • Multi-Stream Capability
    • 2 (RTSP / Web Page), 1080p 60fps (max.)
  • Network Protocols
    • IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP
  • NDI®|HX Capability
    • Yes (NDI HX2)
  •
  • USB

  • Connector
    • USB 3.0
  • Video Formats
    • MJPEG, YUY2
  • Maximum Video Resolution
    • 2160p
  • USB Video Class
    • UVC1.1
  • USB Audio Class
    • UAC1.0
  •
  • Web UI

  • Live Video Preview
    • Yes
  • Camera PTZ Control
    • Pan, Tilt, Zoom, Focus, Preset Control
  • Camera/Image Adjustment
    • Exposure, White Balance, Picture
  • Network Configuration
    • DHCP, IP Address, Gateway, Subnet Mask, DNS
  • Software Tools

  • IP Search & Configuration Tool
    • Support Windows® 7 or later
  • PTZ Management
    • Support Windows® 7 or later
  • PTZ Control Panel
    • Support iPadOS® v11 or later
  • CaptureShare
    • Support Windows® 7 or later
  • Warranty

  • Camera
    • 3 Years
  • Accessories
    • 1 Year
  •
  • Package Contents
    • Camera, Remote Control, Power Adapter, Power Cord, Cable Ties (x 5), Screws (x 10), Cable Fixing Plates (x 2), Ceiling Mount Brackets (x 2), Quick Start Guide
  • Optional Accessories
    • AVer CL01 PTZ Camera Controller, L-Type Ceiling Mount, RS-232 In/Out Cable, Din 8 To D-Sub 9 Cable


* Specifications may vary depending on location and are subject to change without notice.
